Green Pin Safety Dee Shackle
The Green Pin® Dee Shackle BN is a dee shackle with a safety bolt. The shackle offers a double safety (split pin and safety bolt), which prevents accidental unscrewing of the pin. Its long-term durability is assured due to galvanisation. Particularly important for use offshore, the shackle conforms to a wide range of certifications from class societies such as DNV GL. The Green Pin® Dee Shackle BN is suitable for one-leg lifting systems only and is available in a range with a working load limit from 2 up to 85 tons.
- Bow and pin high tensile steel, Grade 6, quenched and tempered
- Meets performance requirements of US Fed. Spec.
- MBL equals 6 x WLL
- Hot dipped galvanized
- -40°C up to +200°C
- Certified
- EN 13889
View Specifications
